CentOS

CentOS7にphpVirtualBoxを設定してWeb管理

毎回ホストマシンから起動するのが面倒な〜と思っていた。

こんな便利なツールがあるなんて知らなかったです。

それがこのphpVirtualBoxです。

設定方法が英語しか無かったのでインストール方法をまとめました。

こんな人にお勧め
  • 操作通りにしたが動かない人
  • エラー時の対応方法なくて困った人
目次
  1. 概要
  2. phpVirtualBoxの設定前の準備
  3. phpVirtualBoxのインストール
  4. Webで起動確認

概要

本稿では、下記の環境にて設定しています。

  • CentOS Linux release 7.9.2009 (Core) mini
  • Apache/2.4.6 (CentOS)
  • PHP 8.0.15
  • VirtualBox 6.1.32

構成図

phpVirtualBoxの設定前の準備

OSのバージョン確認

cat /etc/redhat-release　コマンドでバージョンを確認します。

[root@localhost ~]# cat /etc/redhat-release
CentOS Linux release 7.9.2009 (Core)
[root@localhost ~]#

Apache httpのバージョン確認

httpd -v　コマンドでバージョンを確認します。

[root@localhost ~]# httpd -v
Server version: Apache/2.4.6 (CentOS)
Server built:   Jan 25 2022 14:08:43
[root@localhost ~]#

Apache http インストールされてない方は、↓こちらを見てね。

初心者向け CentOS7.9 に Apache 2.4をインストールいろんなサイトを見ても途中経過が記載してなく不安になる人...

PHPのバージョン確認

php -v　コマンドでバージョンを確認します。

[root@localhost ~]# php -v
PHP 8.0.15 (cli) (built: Jan 18 2022 12:16:19) ( NTS gcc x86_64 )
Copyright (c) The PHP Group
Zend Engine v4.0.15, Copyright (c) Zend Technologies
    with Zend OPcache v8.0.15, Copyright (c), by Zend Technologies
[root@localhost ~]#

phpVirtualBoxに必要なパッケージのSOAPを確認する

yum list installed | grep php-soap　コマンドでバージョンを確認します。

[root@localhost ~]# yum list installed | grep php-soap
php80-php-soap.x86_64                8.0.15-1.el7.remi               @remi-safe
[root@localhost ~]#

PHP インストールされてない方は、↓こちらを見てね。

初心者向け CentOS7.9 に PHP8.0をインストールCentOS 7.9 に PHP 8.0 を yum でインストールする手順について解説します。 実際のコマンドも載せてます。...

VirtualBoxのバージョン確認

yum list installed | grep irtualBox　コマンドでバージョンを確認します。

[root@localhost ~]# yum list installed | grep irtualBox
VirtualBox-6.1.x86_64                6.1.32_149290_el7-1             installed
[root@localhost ~]#

VirtualBox インストールされてない方は、↓こちらを見てね。

初心者向け CentOS7.9 に VirtualBox をインストール操作通りしたが動かない人、エラー時の対処方法を記載してます。...

phpVirtualBox用のユーザを作成

VirtualBoxをインストール時に作成されたグループにphpVirtualBox実行するユーザが必要なため、ユーザを作成します。

VirtualBoxのグループ：vboxusers

本稿では、vboxのユーザを作成します。

adduser vbox

[root@localhost ~]# adduser vbox
[root@localhost ~]#

本稿では、パスワード(pass)を設定します。

passwd vbox

[root@localhost ~]# passwd vbox
ユーザー vbox のパスワードを変更。
新しいパスワード:
よくないパスワード: このパスワードは 8 未満の文字列です。
新しいパスワードを再入力してください:
passwd: すべての認証トークンが正しく更新できました。
[root@localhost ~]#

作成したユーザをvboxusersに追加します。

gpasswd -a vbox vboxusers

[root@localhost ~]# gpasswd -a vbox vboxusers
ユーザ vbox をグループ vboxusers に追加
[root@localhost ~]#

phpVirtualBoxのインストール

ディレクトリをtmpに移動

cd /tmp　コマンドで移動

[root@localhost ~]# cd /tmp
[root@localhost tmp]#

ダウンロード

wget https://github.com/phpvirtualbox/phpvirtualbox/archive/develop.zip

[root@localhost tmp]# wget https://github.com/phpvirtualbox/phpvirtualbox/archive/develop.zip
--2022-02-06 19:02:52--  https://github.com/phpvirtualbox/phpvirtualbox/archive/develop.zip
github.com (github.com) をDNSに問いあわせています... 13.114.40.48
github.com (github.com)|13.114.40.48|:443 に接続しています... 接続しました。
HTTP による接続要求を送信しました、応答を待っています... 302 Found
場所: https://codeload.github.com/phpvirtualbox/phpvirtualbox/zip/refs/heads/develop [続く]
--2022-02-06 19:02:52--  https://codeload.github.com/phpvirtualbox/phpvirtualbox/zip/refs/heads/develop
codeload.github.com (codeload.github.com) をDNSに問いあわせています... 13.112.159.149
codeload.github.com (codeload.github.com)|13.112.159.149|:443 に接続しています... 接続しました。
HTTP による接続要求を送信しました、応答を待っています... 200 OK
長さ: 特定できません [application/zip]
`develop.zip' に保存中

    [    <=>                                                              ] 4,547,449   6.24MB/s 時間 0.7s

2022-02-06 19:02:53 (6.24 MB/s) - `develop.zip' へ保存終了 [4547449]

[root@localhost tmp]#

解凍

develop.zipを/var/www/html/配下に解凍します。

unzip develop.zip -d /var/www/html/　コマンドで解凍します。

[root@localhost tmp]# unzip develop.zip -d /var/www/html/
-bash: unzip: コマンドが見つかりません
[root@localhost tmp]#

「unzip: コマンドが見つかりません」と表示された方は、↓こちらを見てね。

CentOS に zip unzip コマンドがない 下記のようにコマンドが見つかりません　と表示された時になんでやねんと思い備忘録として作成 -bash: zip: コマンドが見つ...


[root@localhost tmp]# unzip develop.zip -d /var/www/html/
Archive:  develop.zip
cf82d58f26ed82d3f7f4b5ba5e80f8754ee48c2f
   creating: /var/www/html/phpvirtualbox-develop/
  inflating: /var/www/html/phpvirtualbox-develop/.dockerignore
  inflating: /var/www/html/phpvirtualbox-develop/.gitignore
 extracting: /var/www/html/phpvirtualbox-develop/.htaccess
  inflating: /var/www/html/phpvirtualbox-develop/CHANGELOG.txt
  inflating: /var/www/html/phpvirtualbox-develop/Dockerfile
  inflating: /var/www/html/phpvirtualbox-develop/GPLv3.txt
  inflating: /var/www/html/phpvirtualbox-develop/LICENSE.txt
  inflating: /var/www/html/phpvirtualbox-develop/README.md
  inflating: /var/www/html/phpvirtualbox-develop/config.php-example
   creating: /var/www/html/phpvirtualbox-develop/css/
  inflating: /var/www/html/phpvirtualbox-develop/css/jquery-ui.css
  inflating: /var/www/html/phpvirtualbox-develop/css/jquery.projectPlugins.css
  inflating: /var/www/html/phpvirtualbox-develop/css/layout.css
  inflating: /var/www/html/phpvirtualbox-develop/css/tipped.css
  inflating: /var/www/html/phpvirtualbox-develop/docker-compose.yml
   creating: /var/www/html/phpvirtualbox-develop/endpoints/
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/api.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/config.js
 extracting: /var/www/html/phpvirtualbox-develop/endpoints/index.html
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/jqueryFileTree.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/language.php
   creating: /var/www/html/phpvirtualbox-develop/endpoints/lib/
   creating: /var/www/html/phpvirtualbox-develop/endpoints/lib/auth/
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/auth/ActiveDirectory.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/auth/Builtin.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/auth/LDAP.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/auth/MySQL.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/auth/OpenMediaVault.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/auth/WebAuth.php
 extracting: /var/www/html/phpvirtualbox-develop/endpoints/lib/auth/index.html
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/authinterface.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/config.php
 extracting: /var/www/html/phpvirtualbox-develop/endpoints/lib/index.html
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/language.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/utils.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/vboxServiceWrappers.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/vboxconnector.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/vboxweb-5.2.wsdl
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/vboxweb-6.0.wsdl
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/vboxweb-6.1.wsdl
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/vboxwebService-5.2.wsdl
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/vboxwebService-6.0.wsdl
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/lib/vboxwebService-6.1.wsdl
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/rdp.php
  inflating: /var/www/html/phpvirtualbox-develop/endpoints/screen.php
   creating: /var/www/html/phpvirtualbox-develop/images/
 extracting: /var/www/html/phpvirtualbox-develop/images/30white.png
 extracting: /var/www/html/phpvirtualbox-develop/images/50px-Question_icon.svg.png
 extracting: /var/www/html/phpvirtualbox-develop/images/50px-Warning_icon.svg.png
 extracting: /var/www/html/phpvirtualbox-develop/images/arrow_grad_dn.png
 extracting: /var/www/html/phpvirtualbox-develop/images/arrow_grad_left.png
 extracting: /var/www/html/phpvirtualbox-develop/images/arrow_grad_right.png
 extracting: /var/www/html/phpvirtualbox-develop/images/arrow_grad_up.png
 extracting: /var/www/html/phpvirtualbox-develop/images/arrow_white_dn.png
 extracting: /var/www/html/phpvirtualbox-develop/images/arrow_white_left.png
 extracting: /var/www/html/phpvirtualbox-develop/images/arrow_white_right.png
 extracting: /var/www/html/phpvirtualbox-develop/images/arrow_white_up.png
 extracting: /var/www/html/phpvirtualbox-develop/images/donate.gif
  inflating: /var/www/html/phpvirtualbox-develop/images/downArrow.png
 extracting: /var/www/html/phpvirtualbox-develop/images/header_grad.png
   creating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-bg_flat_0_aaaaaa_40x100.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-bg_flat_75_ffffff_40x100.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-bg_glass_55_fbf9ee_1x400.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-bg_glass_65_ffffff_1x400.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-bg_glass_75_dadada_1x400.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-bg_glass_75_e6e6e6_1x400.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-bg_glass_95_fef1ec_1x400.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-bg_highlight-soft_75_cccccc_1x100.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-icons_222222_256x240.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-icons_2e83ff_256x240.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-icons_454545_256x240.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-icons_888888_256x240.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jquery-ui/ui-icons_cd0a0a_256x240.png
   creating: /var/www/html/phpvirtualbox-develop/images/jqueryFileTree/
 extracting: /var/www/html/phpvirtualbox-develop/images/jqueryFileTree/directory.png
 extracting: /var/www/html/phpvirtualbox-develop/images/jqueryFileTree/file.png
 extracting: /var/www/html/phpvirtualbox-develop/images/jqueryFileTree/folder_open.png
  inflating: /var/www/html/phpvirtualbox-develop/images/jqueryFileTree/spinner.gif
 extracting: /var/www/html/phpvirtualbox-develop/images/monitor_bl.png
 extracting: /var/www/html/phpvirtualbox-develop/images/monitor_bottom.png
 extracting: /var/www/html/phpvirtualbox-develop/images/monitor_br.png
  inflating: /var/www/html/phpvirtualbox-develop/images/monitor_glossy.png
 extracting: /var/www/html/phpvirtualbox-develop/images/monitor_left.png
 extracting: /var/www/html/phpvirtualbox-develop/images/monitor_right.png
 extracting: /var/www/html/phpvirtualbox-develop/images/monitor_tl.png
 extracting: /var/www/html/phpvirtualbox-develop/images/monitor_top.png
 extracting: /var/www/html/phpvirtualbox-develop/images/monitor_tr.png
  inflating: /var/www/html/phpvirtualbox-develop/images/rightArrow.png
  inflating: /var/www/html/phpvirtualbox-develop/images/spinner.gif
  inflating: /var/www/html/phpvirtualbox-develop/images/treeview-default-line.gif
  inflating: /var/www/html/phpvirtualbox-develop/images/treeview-default.gif
 extracting: /var/www/html/phpvirtualbox-develop/images/upArrow.png
   creating: /var/www/html/phpvirtualbox-develop/images/vbox/
   creating: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/VirtualBox.icns
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/VirtualBox_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/VirtualBox_20px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/VirtualBox_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/VirtualBox_40px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/VirtualBox_48px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/VirtualBox_64px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/VirtualBox_cube_42px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/VirtualBox_win.ico
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/about.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/OSE/about_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/acpi_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/acpi_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/add_host_iface_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/add_host_iface_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/arrow_down_10px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/arrow_left_10px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/arrow_right_10px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/arrow_up_10px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/attachment_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/attachment_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/attachment_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/attachment_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/attachment_remove_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/attachment_remove_disabled_16px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/bgnd_sel_2.jpg
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/blank.gif
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/cd_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/cd_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/cd_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/cd_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/cd_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/cd_disabled_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/cd_unmount_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/cd_unmount_dis_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/cd_unmount_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/chipset_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/chipset_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/close_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/controller_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/controller_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/controller_remove_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/controller_remove_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/cpu_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/description_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/description_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/description_edit_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/description_edit_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/discard_cur_state_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/discard_cur_state_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/discard_cur_state_dis_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/discard_cur_state_dis_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/discard_cur_state_snapshot_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/discard_cur_state_snapshot_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/discard_cur_state_snapshot_dis_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/discard_cur_state_snapshot_dis_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/diskimage_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/exit_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/expanding_collapsing_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/export_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/fd_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/fd_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/fd_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/fd_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/fd_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/fd_disabled_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/fd_unmount_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/fd_unmount_dis_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/floppy_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/floppy_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/floppy_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/floppy_collapse_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/floppy_expand_16px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/fullscreen_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/global_settings_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/global_settings_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/group_abstract_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/guesttools_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/guesttools_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_add_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_add_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_disabled_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_new_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_new_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_new_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_new_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_release_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_release_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_release_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_release_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_remove_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_remove_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_remove_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/hd_remove_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/help_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/ide_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/ide_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/ide_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/ide_collapse_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/ide_expand_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/import_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/list_movedown_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/list_movedown_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/list_moveup_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/list_moveup_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/machine_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/machine_32px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/machine_abstract_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/machine_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/machine_disabled_32px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/menuArrow.gif
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/menuArrow_w.gif
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/name_16px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/node.gif
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/nw_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/nw_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/nw_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/nw_disabled_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_archlinux.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_archlinux_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_debian.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_debian_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_dos.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_fedora.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_fedora_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_freebsd.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_freebsd_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_gentoo.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_gentoo_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_jrockitve.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_l4.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_linux.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_linux22.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_linux24.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_linux24_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_linux26.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_linux26_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_linux_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_linux_other.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_macosx.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_macosx_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_mandriva.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_mandriva_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_netbsd.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_netbsd_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_netware.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_openbsd.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_openbsd_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_opensuse.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_opensuse_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_oracle.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_oracle_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_oraclesolaris.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_oraclesolaris_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_os2_other.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_os2ecs.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_os2warp3.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_os2warp4.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_os2warp45.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_other.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_other_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_qnx.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_redhat.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_redhat_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_solaris.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_solaris_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_turbolinux.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_turbolinux_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_type_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_ubuntu.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_ubuntu_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_virtualbox.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win10.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win10_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win2k.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win2k12_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win2k16_64.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/os_win2k19_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win2k3.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win2k3_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win2k8.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win2k8_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win31.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win7.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win7_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win8.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win81.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win81_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win8_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win95.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win98.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win_other.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_win_other_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_winme.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_winnt4.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_winvista.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_winvista_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_winxp.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_winxp_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_xandros.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/os_xandros_64.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/parallel_port_16px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/preview_empty_228x168px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/preview_full_228x168px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/progress_clone_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_delete_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_export_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_import_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_install_guest_additions_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_media_create_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_media_delete_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_poweroff_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_snapshot_create_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_snapshot_discard_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_snapshot_restore_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_start_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_state_restore_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/progress_state_save_90px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/ram_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/refresh_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/refresh_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/refresh_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/refresh_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/refresh_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/refresh_disabled_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/register_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/remove_host_iface_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/remove_host_iface_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sata_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sata_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sata_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sata_collapse_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sata_expand_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/scsi_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/scsi_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/scsi_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/scsi_collapse_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/scsi_expand_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/select_file_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/select_file_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/serial_port_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/serial_port_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sf_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sf_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sf_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sf_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sf_edit_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sf_edit_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sf_remove_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sf_remove_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sf_settings_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sf_settings_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/site_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/site_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_delete_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_delete_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_delete_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_delete_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_offline_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_online_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_restore_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_restore_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_restore_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_restore_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_show_details_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_show_details_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_show_details_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_show_details_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_take_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_take_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_take_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/snapshot_take_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sort_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sort_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sound_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/sound_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/state_aborted_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/state_discarding_16px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/state_paused_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/state_powered_off_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/state_restoring_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/state_running_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/state_saved_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/state_saving_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/state_stuck_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/status_check_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/status_error_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_collapse_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_expand_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_filter_edit_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_filter_edit_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_movedown_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_movedown_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_moveup_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_moveup_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_new_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_new_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_remove_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_remove_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_unavailable_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/usb_unavailable_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_add_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_add_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_add_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_new_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_new_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_new_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_new_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_release_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_release_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_release_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_release_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_remove_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_remove_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_remove_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vdm_remove_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/video_capture_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/video_capture_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/video_capture_on_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/video_capture_on_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/video_capture_settings_16px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/virtio_scsi_add_16px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/virtio_scsi_add_disabled_16px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/virtio_scsi_collapse_16px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/virtio_scsi_expand_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/virtualbox-hdd.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/virtualbox-ova.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/virtualbox-ovf.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/virtualbox-vbox.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/virtualbox-vdi.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/virtualbox-vhd.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/virtualbox-vmdk.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_add_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_clone_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_clone_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_clone_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_clone_disabled_22px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_delete_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_delete_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_discard_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_discard_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_discard_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_discard_disabled_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_group_create_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_group_create_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_group_name_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_group_name_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_group_remove_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_group_remove_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_new_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_new_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_new_disabled_32px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/vm_open_filemanager_16px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/vm_open_filemanager_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_pause_16px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/vm_pause_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_pause_on_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_pause_on_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_poweroff_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_poweroff_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_poweroff_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_poweroff_disabled_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_reset_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_reset_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_save_state_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_save_state_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_settings_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_settings_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_settings_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_settings_disabled_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_show_logs_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_show_logs_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_shutdown_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_shutdown_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_start_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_start_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_start_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vm_start_disabled_32px.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/vmw_clone_bg.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/vmw_first_run_bg.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/vmw_new_harddisk_bg.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/vmw_new_welcome_bg.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/vmw_ovf_export_bg.png
  inflating: /var/www/html/phpvirtualbox-develop/images/vbox/vmw_ovf_import_bg.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vrdp_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vrdp_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vrdp_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vrdp_disabled_32px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vrdp_on_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vrdp_on_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vtx_amdv_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/vtx_amdv_disabled_16px.png
 extracting: /var/www/html/phpvirtualbox-develop/images/vbox/welcome.png
 extracting: /var/www/html/phpvirtualbox-develop/images/wizard_bg.png
  inflating: /var/www/html/phpvirtualbox-develop/index.html
   creating: /var/www/html/phpvirtualbox-develop/js/
  inflating: /var/www/html/phpvirtualbox-develop/js/canvasimages.js
  inflating: /var/www/html/phpvirtualbox-develop/js/chooser.js
  inflating: /var/www/html/phpvirtualbox-develop/js/datamediator.js
  inflating: /var/www/html/phpvirtualbox-develop/js/dialogs.js
  inflating: /var/www/html/phpvirtualbox-develop/js/eventlistener.js
  inflating: /var/www/html/phpvirtualbox-develop/js/jquery-1.11.2.min.js
  inflating: /var/www/html/phpvirtualbox-develop/js/jquery-ui-1.11.4.min.js
  inflating: /var/www/html/phpvirtualbox-develop/js/jquery.jec-1.3.1.js
  inflating: /var/www/html/phpvirtualbox-develop/js/jquery.projectPlugins.js
  inflating: /var/www/html/phpvirtualbox-develop/js/jquery.scrollTo-min.js
  inflating: /var/www/html/phpvirtualbox-develop/js/jquery.tipped-2.1b.min.js
  inflating: /var/www/html/phpvirtualbox-develop/js/phpvirtualbox.js
  inflating: /var/www/html/phpvirtualbox-develop/js/utils.js
   creating: /var/www/html/phpvirtualbox-develop/languages/
  inflating: /var/www/html/phpvirtualbox-develop/languages/cs.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/da.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/de.xml
 extracting: /var/www/html/phpvirtualbox-develop/languages/en.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/es.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/fr.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/it.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/ja.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/languages.txt
  inflating: /var/www/html/phpvirtualbox-develop/languages/nl.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/pl.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/pt_br.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/ro.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/ru.xml
   creating: /var/www/html/phpvirtualbox-develop/languages/source/
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/cs.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/de.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/en.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/es.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/fr.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/it.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/ja.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/nl.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/parse_vbox_lang.php
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/pl.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/pt_br.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/ro.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/ru.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/zh_cn.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/source/zh_tw.dat
  inflating: /var/www/html/phpvirtualbox-develop/languages/zh_cn.xml
  inflating: /var/www/html/phpvirtualbox-develop/languages/zh_tw.xml
   creating: /var/www/html/phpvirtualbox-develop/packaging/
   creating: /var/www/html/phpvirtualbox-develop/packaging/install-scripts/
  inflating: /var/www/html/phpvirtualbox-develop/packaging/install-scripts/install.bash
  inflating: /var/www/html/phpvirtualbox-develop/packaging/install-scripts/uninstall.bash
   creating: /var/www/html/phpvirtualbox-develop/panes/
  inflating: /var/www/html/phpvirtualbox-develop/panes/about.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/chooser.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/guestNetAdapters.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/login.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/mediumEncryptionPasswords.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsAudio.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsDisplay.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsGeneral.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsGlobalGeneral.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsGlobalLanguage.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsGlobalNetwork.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsGlobalNetworkNATPortForwarding.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsGlobalUsers.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsNetwork.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsParallelPorts.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsPortForwarding.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsSerialPorts.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsSharedFolders.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsStorage.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsSystem.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/settingsUSB.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/tabVMConsole.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/tabVMConsoleRDP.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/tabVMConsoleVNC.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/tabVMDetails.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/tabVMSnapshots.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/tabs.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/toolbar.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/topmenu.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/userEdit.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/vmlogs.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/vmm.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/vmmISCSI.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/vmmModify.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardCloneVM.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardCloneVMAdvanced.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardCopyHD.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardCopyHDAdvanced.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardExportAppliance.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardExportApplianceAdvanced.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardFirstRun.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardImportAppliance.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardImportApplianceAdvanced.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardNewHD.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardNewHDAdvanced.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardNewVM.html
  inflating: /var/www/html/phpvirtualbox-develop/panes/wizardNewVMAdvanced.html
  inflating: /var/www/html/phpvirtualbox-develop/phpvirtualbox.conf
   creating: /var/www/html/phpvirtualbox-develop/rdpweb/
  inflating: /var/www/html/phpvirtualbox-develop/rdpweb/RDPClientUI.swf
  inflating: /var/www/html/phpvirtualbox-develop/rdpweb/license_3rd.txt
  inflating: /var/www/html/phpvirtualbox-develop/rdpweb/swfobject.js
  inflating: /var/www/html/phpvirtualbox-develop/rdpweb/webclient.js
  inflating: /var/www/html/phpvirtualbox-develop/rdpweb/webclient3.html
  inflating: /var/www/html/phpvirtualbox-develop/recovery.php-disabled
   creating: /var/www/html/phpvirtualbox-develop/tightvnc/
  inflating: /var/www/html/phpvirtualbox-develop/tightvnc/VncViewer.jar
  inflating: /var/www/html/phpvirtualbox-develop/vboxinit
[root@localhost tmp]#

フォルダー名の変更

phpvirtualbox-develop　→　vbox　に変更します。

mv /var/www/html/phpvirtualbox-develop /var/www/html/vbox

[root@localhost tmp]# mv /var/www/html/phpvirtualbox-develop /var/www/html/vbox
[root@localhost tmp]#

phpVirtualBoxのconfig.phpの設定

config.phpを設定しますがサンプルをコピーします

config.php-example　→　config.php　にコピーします。

cp /var/www/html/vbox/config.php-example /var/www/html/vbox/config.php

[root@localhost tmp]# cp /var/www/html/vbox/config.php-example /var/www/html/vbox/config.php
[root@localhost tmp]#

config.phpのファイルを編集します。

vi /var/www/html/vbox/config.php

本稿では、ユーザ名：vbox パスワード：pass IPアドレス：192.168.0.24

１２行目　var $username = ‘vbox’;

１３行目　var $password = ‘pass’;

１６行目

変更前　var $location = ‘http://127.0.0.1:18083/’;

変更後　var $location = ‘http://192.168.0.24:18083/’;

２２行目

変更前　var $language = ‘en’;

変更後　var $language = ‘ja’;

下記の内容は、変更後の情報です。

<?php
/**
 * phpVirtualBox example configuration.
 * @version $Id: config.php-example 585 2015-04-04 11:39:31Z imoore76 $
 *
 * rename to config.php and edit as needed.
 *
 */
class phpVBoxConfig {

/* Username / Password for system user that runs VirtualBox */
var $username = 'vbox';
var $password = 'pass';

/* SOAP URL of vboxwebsrv (not phpVirtualBox's URL) */
var $location = 'http://192.168.0.24:18083/';

/* Default language. See languages folder for more language options.
 * Can also be changed in File -> Preferences -> Language in
 * phpVirtualBox.
 */
var $language = 'ja';

/* Set the standard VRDE Port Number / Range, e.g. 1010-1020 or 1027 */
var $vrdeports = '9000-9100';
/* Set the default VRDE address, e.g. 192.168.1.1 */
#var $vrdeaddress = '192.168.1.1';

/*
 *
 * Not-so-common options / tweaking
 *
 */

// Multiple servers example config. Uncomment (remove /* and */) to use.
// Add ALL the servers you want to use. Even if you have the server set
// above. The default server will be the first one in the list.
/*
var $servers = array(
        array(
                'name' => 'London',
                'username' => 'user',
                'password' => 'pass',
                'location' => 'http://192.168.1.1:18083/',
                'authMaster' => true // Use this server for authentication
        ),
        array(
                'name' => 'New York',
                'username' => 'user2',
                'password' => 'pass2',
                'location' => 'http://192.168.1.2:18083/'
        ),
);
*/

// Disable authentication
#var $noAuth = true;

// Host / ip to use for console connections
#var $consoleHost = '192.168.1.40';

// Disable "preview" box
#var $noPreview = true;

// Default preview box update interval in seconds
#var $previewUpdateInterval = 30;

// Preview box pixel width
#var $previewWidth = 180;

// Max number of progress operations to keep in list
var $maxProgressList = 5;

// Change default preview aspect ratio to 1.
// http://www.wikipedia.org/wiki/Aspect_ratio_%28image%29#Previous_and_presently_used_aspect_ratios
#var $previewAspectRatio = 1.6;

// Enable custom VM icons
#var $enableCustomIcons = true;

/*
Exclusively use phpVirtualBox's groups configuration rather than VirtualBox groups.
This has the following effects:

*) Group changes made in phpVirtualBox will not be reflected in VirtualBox programs such as
	VirtualBox and VBoxManage
*) Group changes will not affect which folder a VM is placed in
*) You can rename groups that contain running VMs and move / copy running VMs to groups
*/
#var $phpVboxGroups = true;


/*
Allow to prompt deletion hard disk files on removal from Virtual Media Manager.
If this is not set, files are always kept. If this is set, you will be PROMPTED
to decide whether or not you would like to delete the hard disk file(s) when you
remove a hard disk from virtual media manager. You may still choose not to delete
the file when prompted.
*/
var $deleteOnRemove = true;

/*
 * File / Folder browser settings
 */

// Restrict file types
var $browserRestrictFiles = array('.iso','.vdi','.vmdk','.img','.bin','.vhd','.hdd','.ovf','.ova','.xml','.vbox','.cdr','.dmg','.ima','.dsk','.vfd');

// Restrict locations / folders
#var $browserRestrictFolders = array('D:\\','C:\\Users\\Ian'); // Or something like array('/home/vbox','/var/ISOs')

// Force use of local, web server based file browser instead of going through vboxwebsrv
#var $browserLocal = true;

// Disable file / folder browser.
#var $browserDisable = true;

// Disable Windows drive detection
#var $noWindowsDriveList = true;

// Just list all drives from C:\ - Z:\ without checking if they exist or not.
// This may be required on older Windows systems with more than one drive.
#var $forceWindowsAllDriveList = true;

/*
 * Misc
 */

/*
 * Auto-refresh interval in seconds for VirtualBox host memory usage information.
 * Any value below 3 will be ignored.
 */
var $hostMemInfoRefreshInterval = 5;

/* Show % of free host memory instead of % used */
#var $hostMemInfoShowFreePct = true;

/*
 * VM Memory warnings.
 *
 * If $vmMemoryStartLimitWarn is enabled, each time a VM is started through
 * phpVirtualBox, it will check that the available host memory is greater than
 * the base and video memory of the VM + 50MB (a little bit of overhead). If it
 * is not, a confirmation dialog will be presented to confirm that you want to
 * start the VM.
 *
 * If $vmMemoryOffset is set (and $vmMemoryStartLimitWarn), $vmMemoryOffset
 * megabytes is subtracted from the available host memory before the check is
 * performed by $vmMemoryStartLimitWarn logic. For instance it may be a good
 * idea to always have VM memory requirements + 100MB free. 100 is the default.
 */
#var $vmMemoryStartLimitWarn = true;
#var $vmMemoryOffset = 100;


/*
 * Display guest additions version of a running VM on its Details tab
 */
#var $enableGuestAdditionsVersionDisplay = true;

/* Disable any of phpVirtualBox's main tabs */
#var $disableTabVMSnapshots = true; // Snapshots tab
#var $disableTabVMConsole = true; // Console tab

/* Screen resolutions for console tab */
var $consoleResolutions = array('640x480','800x600','1024x768','1280x720','1440x900');

/* Console tab keyboard layout. Currently Oracle's RDP client only supports EN and DE. */
var $consoleKeyboardLayout = 'EN';

/* Max number of network cards per VM. Do not set above VirtualBox's limit (typically 8) or below 1 */
var $nicMax = 4;

/* Enable advanced configuration items (normally hidden in the VirtualBox GUI)
 * Note that some of these items may not be translated to languages other than English.
 */
#var $enableAdvancedConfig = true;

/* Enable startup / shutdown configuration.
 * This only works in linux and you must add the vboxinit file to
 * your startup scripts list.
 */
#var $startStopConfig = true;

// Authentication library.
// var $authLib = 'Builtin';

// VM ownership
#var $enforceVMOwnership = true;

// Per-user VM quota
#var $vmQuotaPerUser = 2;


// Allow VDE network configuration. This must be supported by the underlying VirtualBox installation!
// If you do not know what VDE networking is - you do not need it, it is probably not supported by your
// VirtualBox installation and will cause errors if enabled.
#var $enableVDE = true;

// Disable setting SATA controllers port count to the max port number found when saving VMs.
#var $disableSataPortCount = true;

/* Enable Parallel Port configuration - EXPERIMENTAL
LPT support may or may not work for you.
!!! VirtualBox LPT support only works in Linux. !!!
*/
#var $enableLPTConfig = true;

/* Enable HardDisk IgnoreFlush configuration. This controls the "ExtraData" setting
 * in "VBoxInternal/Devices/[controller type]/0/LUN#[x]/Config/IgnoreFlush". See
 * Responding to guest IDE/SATA flush requests at:
 * http://www.virtualbox.org/manual/ch12.html#idp12757424
*/
#var $enableHDFlushConfig = true;

/*
 * Event listener timeout in seconds. This is an advanced option that most people will
 * probably not need to change.
 */
#var $eventListenerTimeout = 20;

/* END SETTINGS  */


}

起動設定ファイル作成

virtualboxファイルを新規作成します。

vi /etc/default/virtualbox

# virtualbox defaults file
VBOXWEB_USER=vbox
VBOXWEB_HOST=192.168.0.24

バックグランドで起動確認

ps aux | grep vboxweb

[root@localhost ~]# ps aux | grep vboxweb
root     32086  0.0  0.0 112824   980 pts/0    R+   19:17   0:00 grep --color=auto vboxweb
[root@localhost ~]#

vboxユーザで実行されてないことが確認できます。

vboxweb-serviceを再起動します。

systemctl restart vboxweb-service

[root@localhost ~]# systemctl restart vboxweb-service
[root@localhost ~]#

Apache httpdを再起動します。

systemctl restart httpd

[root@localhost ~]# systemctl restart httpd
[root@localhost ~]#

バックグランドで起動確認

ps aux | grep vboxweb

[root@localhost ~]# ps aux | grep vboxweb
vbox     32126  0.1  0.1 661116  7380 ?        Sl   19:18   0:00 /usr/lib/virtualbox/vboxwebsrv --background -H 192.168.0.24
root     32185  0.0  0.0 112828   980 pts/0    S+   19:19   0:00 grep --color=auto vboxweb
[root@localhost ~]#

vboxユーザで実行さたことが確認できます。

SELinuxの無効にしてない方はアクセスできるように下記のコマンドで設定します。

semanage fcontext -a -s system_u -t httpd_sys_content_t -r s0 “/var/www/html/vbox(/.*)?”

restorecon /var/www/html/ -R

semanage port -a -t http_port_t -p tcp 18083

Webで起動確認

本稿では、http://192.168.0.24/vbox/ で起動確認します。

ユーザー名：admin　　パスワード：admin　を入力して「ログイン」をクリックする。

ログイン後の画面になります。

インフラエンジニアを目指す方へ



COMMENT

メールアドレスが公開されることはありません。 ※ が付いている欄は必須項目です

CAPTCHA


RELATED POST
